Manufacturer

Yamaha

Model Year

2024

Model

Drive2 Adventurer Sport 2+2 AC

Model Code

NA

Color

Titan

Battery

Six 8V Trojan® T-105

Charger - Delta-Q

Six 8V Trojan® T-105

Charger - Delta-Q

Engine

48V AC motor

Motor controller unit - Toyota® Industries-built

48V AC motor

Motor controller unit - Toyota® Industries-built

Horsepower

6.7 hp (5.0 kw)

Length

Overall - 108.9 in. (2,765 mm)

Height

Overall (without suntop) - 50 in. (1,270 mm)

Floor board - 14.4 in. (365 mm)

Overall (without suntop) - 50 in. (1,270 mm)

Floor board - 14.4 in. (365 mm)

Width

Overall - 50.9 in. (1,294 mm)

Weight

Dry - 788.1 lb. (385 kg)

Wheelbase

64.7 in. (1,643 mm)

Ground Clearance

Minimum - 5.3 in. (135 mm)

Brakes

Self adjusting rear drum

Suspension

Front - Tru-Trak II™ fully independent automotive-style strut

Rear - Unit swing arm with coil springs over hydraulic shock absorbers

Front - Tru-Trak II™ fully independent automotive-style strut

Rear - Unit swing arm with coil springs over hydraulic shock absorbers

Tires

20.00 x 10.00-8.00 (4-ply rating)

Seating

Capacity - 4 persons

Front - Seamless, fabric-backed vinyl bonded to pure, virgin foam contoured seat cushions and mated to a warp and moisture-resistant polypropylene bottom, strengthened with plated steel inserts

Rear - Hinged seating platform with vinyl covered seat bottom cushion and contoured backrest

Color - Stone

Capacity - 4 persons

Front - Seamless, fabric-backed vinyl bonded to pure, virgin foam contoured seat cushions and mated to a warp and moisture-resistant polypropylene bottom, strengthened with plated steel inserts

Rear - Hinged seating platform with vinyl covered seat bottom cushion and contoured backrest

Color - Stone

Load Capacity

Cargo bed - 250 lb. (114 kg)

Steering

Self-compensating double reduction helical rack-and-pinion, permanently lubricated with sealed bearings and greaseless tie-rod ends

Additional Colors

Arctic Drift

Carbon

Coral Red

Glacier

Onyx

Peridot

Titan

Arctic Drift

Carbon

Coral Red

Glacier

Onyx

Peridot

Titan

Frame

HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame mated to a polypropylene structural floor. Frame is protected withelectro-deposition epoxy-based coating and a electrostatic applied polyester/urethane powder topcoat.

Body - Custom-formulated thermoplastic olefin, painted with a two-part topcoat of high-luster automotive grade polyurethane

Bumpers - Front 5 mph energy-absorbing

HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame mated to a polypropylene structural floor. Frame is protected withelectro-deposition epoxy-based coating and a electrostatic applied polyester/urethane powder topcoat.

Body - Custom-formulated thermoplastic olefin, painted with a two-part topcoat of high-luster automotive grade polyurethane

Bumpers - Front 5 mph energy-absorbing

Warranty

Standard 2-year limited vehicle
